Lenovo

Lenovo ThinkStation P2 Tower Gen 2

Model ThinkStation P2 Tower Gen 2

Price coming soon

Leave your email and we'll tell you when it's available to order.

SKU: TS-3150
EAN: 0828143024642

Overview

Lenovo ThinkStation P2 Tower Gen 2. Processor family: Intel Core Ultra 5, Processor model: 235A. Internal memory: 32 GB, Internal memory type: DDR5-SDRAM, Memory clock speed: 5600 MHz. Total storage capacity: 512 GB, Storage media: SSD. On-board graphics card model: Intel® Graphics. Operating system installed: Windows 11 Pro. Power supply: 500 W. Chassis type: Tower. Product type: Workstation. Weight: 9.67 kg

Specifications

Performance

Memory (RAM): 32 GB
Motherboard chipset: Intel W880
Trusted Platform Module (TPM): Yes
Product type: Workstation
Trusted Platform Module (TPM) version: 2.0

Storage

Storage: 512 GB
Total storage capacity: 512 GB
Storage media: SSD
Optical drive type: No
Total SSDs capacity: 512 GB
Number of SSDs installed: 1
SSD capacity: 512 GB
SSD interface: PCI Express 4.0
NVMe: Yes
SSD form factor: M.2
M.2 SSD size: 2280 (22 x 80 mm)
Self-Encrypting Drive (SED): Yes
Card reader integrated: No

Design

Chassis type: Tower
Cable lock slot: Yes
Cable lock slot type: Kensington

Power

Power supply: 500 W
80 PLUS certification: 80 PLUS Platinum

Memory

Internal memory: 32 GB
Maximum internal memory: 128 GB
Internal memory type: DDR5-SDRAM
Memory layout (slots x size): 2 x 16 GB
Memory slots: 4x DIMM
Memory clock speed: 5600 MHz
Memory channels: Dual-channel

Network

Ethernet LAN: Yes
Ethernet LAN data rates: 10,100,1000 Mbit/s
Wi-Fi: No
Ethernet interface type: Gigabit Ethernet

Graphics

Discrete graphics card: No
On-board graphics card: Yes
Discrete graphics card model: Not available
On-board GPU manufacturer: Intel
On-board graphics card family: Intel Graphics
On-board graphics card model: Intel Graphics
Graphics card: Intel Graphics

Software

Operating system language: DEU
Operating system installed: Windows 11 Pro

Processor

Processor manufacturer: Intel
Processor family: Intel Core Ultra 5
Processor generation: Intel Core Ultra (Series 2)
Processor model: 235A
Processor cores: 14
Processor threads: 14
Processor boost frequency: 5 GHz
Performance cores: 6
Efficient cores: 8
Performance-core Max Turbo Frequency: 5 GHz
Efficient-core Max Turbo Frequency: 4.4 GHz
Performance-core base frequency: 3.4 GHz
Efficient-core base frequency: 2.9 GHz
Processor cache: 24 MB
Processor cache type: Smart Cache

Ports & interfaces

USB 2.0 ports quantity: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
USB 3.2 Gen 2x2 Type-C ports quantity: 1
DisplayPorts quantity: 2
HDMI ports quantity: 1
HDMI version: 2.1
Ethernet LAN (RJ-45) ports: 1
Combo headphone/mic port: Yes
Line-out: Yes
Microphone in: Yes

Processor special features

Intel® Smart Cache: Yes

Neural processor unit (NPU)

Neural processor unit (NPU): Intel AI Boost
Sparsity support: Yes
Windows Studio effects support: Yes
AI software frameworks supported by NPU: OpenVINO,Windows ML,DirectML,ONNX RT,WebNN
Total processor performance up to: 27 TOPs
NPU performance up to: 13 TOPs
GPU performance up to: 6 TOPs
