iiyama
iiyama ProLite TF1534MC-B8X computer monitor
Model TF1534MC-B8X
Overview
The ProLite TF1534MC-B8X is a 15” Open Frame touchscreen monitor designed for integration into kiosks, retail systems, interactive displays and custom installations. Its 10-point PCAP touch technology provides accurate multi-touch operation, while the edge-to-edge glass surface offers durability, scratch resistance and a clean, professional appearance. With IP65-rated front protection, the screen is resistant to dust and splashing water from the front, making it suitable for demanding public and commercial environments. The anti-fingerprint coating helps keep the display clear and easy to use, even with frequent interaction. For applications requiring additional protection, the Touch Through-Glass function allows reliable touch operation through a glass overlay up to 6 mm. The monitor can be installed in landscape, portrait or face-up orientation, while optional Open Frame mounting brackets support easy and secure integration into different installation designs. For ease of integration, the monitor can be equipped with optional external mounting brackets ( OMK1-1 ).
Specifications
Performance
- NVIDIA G-SYNC
- No
- AMD FreeSync
- No
- Low Blue Light technology
- Yes
- Palm rejection
- Yes
Display
- Screen size
- 15"
- Display diagonal
- 15"
- Display resolution
- 1024 x 768 pixels
- HD type
- XGA
- Native aspect ratio
- 4:3
- Display technology
- LED
- Panel type
- TN
- Touchscreen
- Yes
- Touchscreen technology
- Projected capacitive system
- Number of simultaneous touchpoints
- 10
- Display brightness (peak)
- 350 cd/m²
- Display brightness (typical)
- 300 cd/m²
- Display brightness
- 300 cd/m²
- Response time
- 8 ms
- Screen shape
- Flat screen
- Contrast ratio (typical)
- 800:1
Design
- Market positioning
- Business
- Product colour
- Black
- Front bezel colour
- Black
Power
- Energy efficiency class (SDR)
- D
- Energy efficiency class (HDR)
- Not available
- Energy consumption (SDR) per 1000 hours
- 9 kWh
- Power consumption (typical)
- 9 W
- Power consumption (standby)
- 1.5 W
- Power consumption (off)
- 0.3 W
- AC adapter output voltage
- 12 V
- Power supply type
- External
Ergonomics
- VESA mounting
- Yes
- Panel mounting interface
- 100 x 100 mm
- Cable management
- Yes
- Cable lock slot
- Yes
- Cable lock slot type
- Kensington
- Height adjustment
- No
- On Screen Display (OSD)
- Yes
- On Screen Display (OSD) languages
- CHI (TR),DEU,ENG,ESP,FRE,ITA,JPN
Multimedia
- Built-in speaker(s)
- No
- Built-in camera
- No
Other features
- International Protection (IP) code
- IP65
- Compatible operating systems
- All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section.
- Positional accuracy
- 2 mm
- AC adapter included
- Yes
- User controls
- picture (contrast, brightness, H.position, V.position, phase, clock, auto adjust), advanced (color temp., sharpness), OSD (time out, position, H-position, V-position, Touch switch), option (reset, language, source select, display mode, factory)
- Brightness
- 300 cd/m²
- Packaging content
- AC adapter
- Active display area (W x H)
- 304 x 228 mm
- Touch method
- stylus, finger, glove (latex)
- Weight
- 2700 g
- Height
- 267 mm
- Width
- 338 mm
- Depth
- 45 mm
- Control panel
- Menu, Scroll up/ Brightness, Scroll down/ Contrast, Select, Power
- Compliance certificates
- CE,cULus,EAC,REACH,RoHS,WEEE
Packaging data
- Package width
- 355 mm
- Package depth
- 435 mm
- Package height
- 165 mm
- Package weight
- 4000 g
- USB cable length
- 1.8 m
Sustainability
- Sustainability certificates
- ErP
Packaging content
- Cables included
- AC,USB,HDMI,DisplayPort
- Quick start guide
- Yes
- DisplayPort cable length
- 1.8 m
- HDMI cable length
- 1.8 m
- Power cable length
- 1.8 m
Ports & interfaces
- Built-in USB hub
- No
- USB Touch port
- Yes
- VGA (D-Sub) ports quantity
- 1
- HDMI
- Yes
- HDMI ports quantity
- 1
- DisplayPorts quantity
- 1
- Headphone out
- No
- HDCP
- Yes
Weight & dimensions
- Width (with stand)
- 338 mm
- Depth (with stand)
- 45 mm
- Height (with stand)
- 267 mm
- Weight (with stand)
- 2700 g
