iiyama OTF2216MC-B1 21.5" Full HD VA Monitor
Model OTF2216MC-B1
Overview
Built into a rugged, edge-to-edge glass bezel the ProLite OTF2216MC-B1 guarantees high durability and scratch-resistance, making it perfect for high use public facing applications. Landscape, portrait and face-up orientation ensure flexibility in any type of installation. It offers a brightness of up to 935 cd/m2, the content displayed will be visible even in very bright environments. The anti-glare display is UV resistant and IP65 protected, ensuring durability against sunlight, dust and water resistance from the front, additionally it can operate in temperatures ranging from -20 ̊C up to +60 ̊C and 24/7. The anti-fingerprint coating ensures a smoother touch. A reliable solution for pick-up points and kiosks. A proximity sensor turns off the screen when no one is present, an ambient light sensor adjusts screen brightness, and a temperature sensor controls fan speed for cooling, resulting in energy savings and extended product durability. For ease of integration, the ProLite OTF2216MC-B1 can be equipped with optional external mounting brackets ( OMK3-1 ) making it an ideal solution for kiosk integrators, industrial environments, control rooms and interactive multimedia.
Specifications
Performance
- Operating hours (hours/days)
- 24/7
- Palm rejection
- Yes
Display
- Screen size
- 21.5"
- Display diagonal
- 21.5"
- Display resolution
- 1920 x 1080 pixels
- HD type
- Full HD
- Native aspect ratio
- 16:9
- Display technology
- LCD
- Panel type
- VA
- Touchscreen
- Yes
- Touchscreen technology
- Projected capacitive system
- Touch technology
- Multi-touch
- Number of simultaneous touchpoints
- 10
- Display brightness (peak)
- 1100 cd/m²
- Display brightness (typical)
- 1100 cd/m²
- Display brightness
- 935 cd/m²
- Response time
- 25 ms
- Screen shape
- Flat screen
Design
- Market positioning
- Office
- Product colour
- Black
- Front bezel colour
- Black
- Glass thickness
- 3.15 mm
Power
- Energy efficiency class (SDR)
- E
- Energy efficiency class (HDR)
- Not available
- Energy consumption (SDR) per 1000 hours
- 15.5 kWh
- Power consumption (typical)
- 43 W
- Power consumption (standby)
- 1.5 W
- Power consumption (off)
- 0.3 W
- AC adapter output voltage
- 12 V
- Power supply type
- External
- Energy efficiency scale
- A to G
Network
- Wi-Fi
- No
- Ethernet LAN
- Yes
Ergonomics
- VESA mounting
- Yes
- Panel mounting interface
- 100 x 100 mm
- Cable management
- Yes
- On Screen Display (OSD)
- Yes
- On Screen Display (OSD) languages
- CHI (TR),DEU,ENG,ESP,FRE,ITA,JPN
- Number of OSD languages
- 7
Packaging data
- Package width
- 608 mm
- Package depth
- 150 mm
- Package height
- 400 mm
- Package weight
- 4500 g
Sustainability
- Sustainability certificates
- ErP
Packaging content
- Cables included
- AC,USB,HDMI,DisplayPort
- Remote control included
- Yes
- Quick start guide
- Yes
Ports & interfaces
- USB Touch port
- Yes
- VGA (D-Sub) ports quantity
- 1
- DVI port
- No
- HDMI
- Yes
- HDMI ports quantity
- 1
- DisplayPorts quantity
- 1
- Headphone out
- Yes
- HDCP
- Yes
Weight & dimensions
- Width (with stand)
- 520 mm
- Depth (with stand)
- 42.5 mm
- Height (with stand)
- 315 mm
- Weight (with stand)
- 4600 g
- Width (without stand)
- 520 mm
- Depth (without stand)
- 42.5 mm
- Height (without stand)
- 315 mm
- Weight (without stand)
- 4600 g
Operational conditions
- Operating temperature (T-T)
- -20 - 60 °C
