TP-Link Omada DR3220v-4G Router

Model DR3220v-4G

Price coming soon

Leave your email and we'll tell you when it's available to order.

SKU: TS-100915
EAN: 1210002608411

Overview

TP-Link Omada DR3220v-4G. WAN connection type: RJ-45. Wi-Fi band: Dual-band (2.4 GHz / 5 GHz), WLAN data transfer rate (max): 2402 Mbit/s, Wi-Fi standards: 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax). Ethernet LAN interface type: Gigabit Ethernet, Ethernet LAN data rates: 10,100,1000 Mbit/s, Cabling technology: 10/100/1000Base-T(X). Security algorithms: WPA-Enterprise, WPA-Personal, WPA2-Enterprise, WPA2-Personal, WPA3-Enterprise, WPA3-Personal. Voice codecs: G.711a, G.711ulaw, G.722, G.726, G.729ab

Specifications

Design

Product colour: Black
Wall mountable: Yes
Indication light: Yes
LED indicators: DSL,LAN,USB,WLAN
Product type: Tabletop router

Power

Power source type: AC
Output voltage: 12 V
Output current: 3.3 A

Antenna

Antenna design: External
Antenna gain level (max): 4.5 dBi
Antennas quantity: 3
Detachable antenna(s): Yes

Network

Ethernet LAN: Yes
Ethernet LAN interface type: Gigabit Ethernet
Ethernet LAN data rates: 10,100,1000 Mbit/s
Cabling technology: 10/100/1000Base-T(X)
Networking standards: IEEE 802.11a,IEEE 802.11ac,IEEE 802.11ax,IEEE 802.11b,IEEE 802.11g,IEEE 802.11n,IEEE 802.1Q,IEEE 802.3,IEEE 802.3ab,IEEE 802.3u,IEEE 802.3x
Port triggering: Yes
Load balancing system: Yes
Dynamic DNS (DDNS): Yes
Policy-based routing: Yes
Static route: Yes
Built-in FTP server: Yes
VPN support: IPSec, PPTP, L2TP, OpenVPN, WireGuard, GRE, SSL VPN

Security

Security algorithms: WPA-Enterprise,WPA-Personal,WPA2-Enterprise,WPA2-Personal,WPA3-Enterprise,WPA3-Personal
Guest access: Yes
Access Control List (ACL): Yes
URL filtering: Yes
System event log: Yes
DMZ support: Yes
Network address translation (NAT): Yes

Protocols

DHCP client: Yes
DHCP server: Yes
Universal Plug and Play (UPnP): Yes
Voice codecs: G.711a,G.711ulaw,G.722,G.726,G.729ab

DSL features

ADSL: Yes
ADSL2: Yes
ADSL2+: Yes
VDSL2: Yes

WAN connection

Ethernet WAN: Yes
DSL WAN: Yes
SIM card slot: No
3G/4G USB modem compatibility: Yes
WAN connection type: RJ-45

Packaging content

Cables included: LAN (RJ-45),Phone
AC adapter included: Yes
Antenna included: Yes

Ports & interfaces

Ethernet LAN (RJ-45) ports: 4
USB port: Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
RJ-11 ports quantity: 3
DC-in jack: Yes

Management features

Web-based management: Yes
Quality of Service (QoS) support: Yes
Reset button: Yes
MU-MIMO technology: Yes

Wireless LAN features

Wi-Fi band: Dual-band (2.4 GHz / 5 GHz)
WLAN data transfer rate (max): 2402 Mbit/s
Wi-Fi standards: 802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac),Wi-Fi 6 (802.11ax)
WLAN data transfer rate (first band): 574 Mbit/s
WLAN data transfer rate (second band): 2402 Mbit/s
